| Configuration | Range with Storage Drawer |
| Cooktop Burner Type | Radiant Smoothtop |
| Cooktop Surface | One-Piece Upswept White Patterned Ceramic Glass |
| Control Location | Backsplash |
| Element - Left Front | 6" 1200W |
| Element - Left Rear | 8" 2000W |
| Element - Right Front | 9"/6" 3100W Power Boil |
| Element - Right Rear | 6" 1200W |
| Control Type | Digital Temperature Display Electronic Touchpads |
| Cooking System | Traditional |
| Melt Setting | Yes |
| Heating Element "ON" Indicator Light | 1 |
| Hot Surface Indicator Lights | 1 |
| Interior Oven Light | 1 Incandescent |
| Oven Cleaning Type | Standard Clean |
| Oven Control Features | Audible Preheat Signal Auto Oven Shut-Off with Override Certified Sabbath Mode Control Lock Capability Delay Bake Option (Time Bake) Electronic Clock & Kitchen Timer Hi / Low Broil Oven "ON" Light |
| Oven Features | 4-Pass Bake Element 4-Pass Broil Element |
| Oven Rack Features | 2 Oven Racks 6 Rack Positions |
| Storage Drawer Features | Removable Full-Width |
| Cooking Technology | Traditional |
CAPACITY |
|
|---|---|
| Total Capacity (cubic feet) | 5.3 cu ft |
APPEARANCE |
|
|---|---|
| Control Knobs | Glass Bisque |
| Color Appearance | White |
| Handle | Color-Matched Designer Style |
| Oven Door Features | Big View Oven Window Glass Door |
| Textured Steel Side Panels | Yes |
WEIGHTS & DIMENSIONS |
|
|---|---|
| Approximate Shipping Weight | 161 lb |
| Cabinet Width | 30 in |
| Net Weight | 141 lb |
| Oven Interior Dimensions (W x H x D) (in.) | 24-1/8 x 19-1/2 x 19-3/8 |
| Overall Height | 47 in |
| Overall Width | 29 7/8 in |
| Overall Depth | 28 in |
| Depth with Door Open | 47 7/8 in |
| Depth Without Handle | 25 1/2 in |
| Height to Cooking Surface (in.) | 35 3/4 - 36 1/2 |
POWER / RATINGS |
|
|---|---|
| Amp Rating at 208V | 40 |
| Amp Rating at 240V | 40 |
| Bake Wattage | 2585W |
| Broiler Wattage | 3410W |
| KW Rating at 208V | 8.3 |
| KW Rating at 240V | 11.0 |
CLAIMS & CERTIFICATIONS |
|---|
| MADE IN AMERICA: 70 to 90% U.S. Content |
| UL |
ACCESSORIES |
|
|---|---|
| Cooktop Cleaning | Cream Included Sponge |
WARRANTY |
|
|---|---|
| Parts Warranty | Limited 1-year entire appliance |
